INDOOR  20  INDOOR
      20
            PROIETTORI 48Vdc / 48Vdc PROJECTORS




            Modulo di illuminazione LED non
            dimmerabile lineare regolabile
            antiabbagliamento a luce diffusa.
            Struttura in alluminio con diffusore in
            policarbonato bianco.
            Sistema ad incastro magnetico
            installabile nei binari 48V.
            Non è possibile installare il corpo
            illuminante negli angoli.
            Finiture: bianco o nero opaco.

            Adjustable non dimmable linear
            anti-glare LED lighting module with
            diffused light.
            Aluminium structure with white
            polycarbonate diffuser.
            Magnetic interlocking system that can
            be installed in 48V tracks. It is not
            possible to install
            the luminaire in corners.
            Finishes: matte white or black


                    IP20  gr  m 3
                         323  0,0006  30.000
                         479  0,0008
                         615  0,0011
             LIGHT SOURCE                     FINISHED    CODE       CCT      FLUX
            LED                               Bianco      GFA1300    3000K    1123lm
            12W  |  48Vdc                     White
            CRI >90                                                                                   214

            BEAM                                                                                  60       78  0 - 60°
                                                                                                      236    23
                                              Nero        GFA1310    3000K    1063lm
              38°                             Black



            LED                               Bianco      GFA1301    3000K    1631lm
            18W  |  48Vdc                     White                                                  328
            CRI >90
            BEAM                                                                               60          78  0 - 60°
                                                                                                     348     23
                                              Nero        GFA1311    3000K    1595lm
              38°                             Black



            LED                               Bianco      GFA1302    3000K    2132lm
            24W  |  48Vdc                     White
            CRI >90                                                                                 443
            BEAM                                                                            60             78  0 - 60°
                                                                                                   463       23
                                              Nero        GFA1312    3000K    2103lm
              38°                             Black






            BINARI PER PROIETTORI 48Vdc
            TRACK FOR PROJECTORS 48Vdc
            Vedi pagine / see pages
            28-31
