INDOOR  18  INDOOR
       8
      1
            PROIETTORI 48Vdc / 48Vdc PROJECTORS









            Modulo di illuminazione LED non dimmerabile lineare
            antiabbagliamento a luce diffusa.
            Struttura in alluminio con diffusore in policarbonato bianco.
            Sistema ad incastro magnetico installabile nei binari 48V.
            Non è possibile installare il corpo illuminante negli angoli.
            Finiture: bianco o nero opaco.
            Non dimmable linear anti-glare LED lighting module
            with diffused light.
            Aluminium structure with white polycarbonate diffuser.
            Magnetic interlocking system that can
            be installed in 48V tracks.
            It is not possible to install the luminaire in corners.
            Finishes: matte white or black.





                    IP20  gr  m 3
                         188  0,0004  30.000
                         364  0,0007
                         576  0,0009
             LIGHT SOURCE                     FINISHED    CODE       CCT      FLUX
            LED                               Bianco      GFA1280    3000K    1123lm
            12W  |  48Vdc                     White
            CRI >90                                                                                     214

            BEAM                                                                                   27   234  45 23
                                              Nero        GFA1290    3000K    1063lm
              38°                             Black



            LED                               Bianco      GFA1281    3000K    2132lm
            24W  |  48Vdc                     White                                                 452
            CRI >90                                                                          27              45
            BEAM                                                                                    462       23
                                              Nero        GFA1291    3000K    2102lm
              38°                             Black



            LED                               Bianco      GFA1282    3000K    2895lm
            36W  |  48Vdc                     White                                              680
            36W  |  48Vdc
            CRI >90                                                                                          45
            BEAM                                                                       27        690          23
                                              Nero        GFA1292    3000K    2787lm
              38°                             Black






            BINARI PER PROIETTORI 48Vdc
            TRACK FOR PROJECTORS 48Vdc
            Vedi pagine / see pages
            28-31
