                                                                                                                  INDOOR




          Modulo di illuminazione LED non                                                                           PROIETTORI 48Vdc / 48Vdc PROJECTORS
          dimmerabile lineare a luce diffusa.
          Struttura in alluminio con diffusore
          in policarbonato bianco.
          Sistema ad incastro magnetico
          installabile nei binari 48V.
          Non è possibile installare il corpo
          illuminante negli angoli.
          Finiture: bianco o nero opaco.

          Non dimmable linear LED lighting
          module with diffused light.
          Aluminium structure with white
          polycarbonate diffuser.
          Magnetic interlocking system that
          can be installed in 48V tracks.
          It is not possible to install the
          luminaire in corners.
          Finishes: matt white or black.




                  IP20  gr  m 3
                      221  0,0005  30.000
                      413  0,0009
                      632  0,0012
          LIGHT SOURCE                      FINISHED   CODE       CCT      FLUX
          LED                               Bianco     GFA1260    3000K    1069lm
          12W  |  48Vdc                     White
          CRI >90                                                                                   291

          BEAM                                                                                27    305   45  23
                                            Nero       GFA1270    3000K    1009lm
           110°                             Black



          LED                               Bianco     GFA1261    3000K    2168lm
          24W  |  48Vdc                     White
          CRI >90                                                                              586
          BEAM                                                                        27                  45
                                                                                               600         23
                                            Nero       GFA1271    3000K    2048lm
           110°                             Black



          LED                               Bianco     GFA1262    3000K    2515lm
          36W  |  48Vdc                     White
          CRI >90
          BEAM
                                            Nero       GFA1272    3000K    2472lm
           110°                             Black
                                                                                           881

                                                                              27
                                                                                           895            45  23

          BINARI PER PROIETTORI 48Vdc
          TRACK FOR PROJECTORS 48Vdc
          Vedi pagine / see pages
          28-31
