508 OUTDOOR
PROIETTORI E ARMATURE STRADALI / STEPLIGHTS AND STREET LIGHTING

Armatura stradale.
Struttura in alluminio pressofuso.
Finitura in grigio opaco.
Attacco al palo in alluminio pressofuso
idoneo per pali di diametro 62 mm.
Diffusore in vetro temperato.
Modulo LED e trasformatore inclusi.
Altezza di installazione:
GES570 max 6 metri;
GES571 max 10 metri.
Street lighting.
Die-cast aluminium structure.
Matt grey finish.
Support attachment in die-cast
aluminium, ideal for supports with
diameter 62 mm.
Tempered glass diffuser.
LED module and transformer included.
Installation height:
GES570 max 6 metres;
GES571 max 10 metres.

IP65 gr m 3
2230 0,0065 30.000
3530 0,0115
4830 0,0188
LIGHT SOURCE FINISHED CODE CCT FLUX
LED Grigio opaco GES570 4000K 4500lm
50W | 220-240Vac Matt Grey 213,5
CRI >70

BEAM 62
460
100°

LED Grigio opaco GES571 4000K 9000lm
100W | 220-240Vac Matt Grey 264
CRI >70
BEAM 68

538
100°

CODE
Accessorio per il collegamento GESC05 gr Ø80
dell’armatura stradale al palo. Ø64
Diametro massimo 930
del palo Ø 64 mm
Accessory for connecting street 240
light to the pole.
Maximum diameter
of the pole Ø 64 mm Ø50
