Configurate your code according to your needs:
Illumination Type Size (Length) – CCT (Kelvin) – Colour & – Diffuser – Dimming Type
Finish
3917-04 058 3 B P N
Recessed Trimless L580 • 15W • 2565Lm 3000k Black Opal On-off
34 086 4 W D3
L860 • 22W • 3848Lm 4000k White DALI
33 114 D4
L1140 • 30W • 5130Lm Push
13,5
142
74 L1420 • 37W • 6413Lm
170
L1700 • 44W • 7695Lm
198
L1980 • 51W • 8978Lm
226
L2260 • 59W • 10260Lm
Code Example: 3911-04086-3-W-D3
SASA
Illumination Type Size (Length) – CCT (Kelvin) – Colour & – Diffuser – Dimming Type
Finish
3917-04 086 3 B P N
Recessed Trimless L860 • 22W • 3848Lm 3000k Black Opal On-off
Installation of recessed linear trimless Create your own Code:
Τοποθέτηση χωνευτού γραμμικού trimless
Extra Parts:
No 3917-RD3 • 3000K
No 3917-RD4 • 4000K
5 dots Antiglare Module No 3917-BC WARRANTY
1. Κόψτε ένα άνοιγμα στην επιφάνεια της 2. Συνδέστε το τροφοδοτικό με την άκρη του 3. Εγκαταστήστε το φωτιστικό στην L130mm • 4W • 500Lm Blind Cover
γυψοσανίδας ανάλογο με το μέγεθος AC και περιστρέψτε το φωτιστικό έτσι ώστε γυψοσανίδα. Στοκάρετε και βάψτε στο with 30° reflector
του φωτιστικού. να περάσει μέσα από το άνοιγμα. επιθυμητό χρώμα. Suitable for Free Combination Optionally used to create black areas between light
W AR RA NTY
1. Cut a hole on the surface. The hole 2. Connect the driver to the AC end and 3. Install the linear into the surface board.
size depends on the model of the light. turn the linear to pass through the hole. Plaster and paint with desired colour.
Για την σωστή εφαρμογή των χωνευτών προϊόντων προτού ξεκινήσετε τη διαδικασία “χώνευσης”,
πρέπει να έχετε δείγμα του προϊόντος που πρόκειται να τοποθετήσετε.
For the correct placement of recessed lights you must have a sample of the product
before you proceed with the cutting of the plasterboard. NOTE: Different sizes, different CCT and Level of output Lumen upon request
