Driver e alimentazione Driver and power supply
ROUND superficie surface

nero bianco nero
bianco
Driver attacco magnetico black Cover per driver remoto white black
white
Magnetic attachment driver Cover for remote driver
OTD100 100W OTCVB OTCVN
Driver magnetico da installare Vin 220-240Vac Compatibile con driver OTDS100
Vout 48 Vdc
direttamente a binario. Compatibile e OTDS200.
Ampere 2.1 A 65
con serie ROUND 48Vdc - SQUARE Compatible with OTDS100 and
280 16 IP20
48Vdc. OTDS200 drivers.
Magnetic driver to be installed directly 42 45
on track. Compatible with ROUND 48Vdc
- SQUARE 48Vdc series.
20
282 300
BINARI MAGNETICI 48V 48V MAGNETIC TRACKS
Driver remoto per sospensione rigida
OTD150 150W OTDRC 100W
Vin 220-240Vac Remote driver for rigid suspension Vin 100-240Vac
Vout 48 Vdc Vout 48 Vdc
Ampere 3.1 A Ampere 2.1 A
Articolo necessario per l’opzione di
IP20 IP20
sospensione rigida e alimentazione in remoto, ROUND SUPERFICIE ROUND SURFACE
indispensabile il collegamento al modulo di
97
input elettrico (OTMIN-OTMIB). Disponibile asta
con cover (OTPLDB-OTPLDN).
280 16
Item needed for rigid suspension and remote 30
power supply option, indispensable connection
42
to electrical input module (OTMIN-OTMIB).
129
Rod with cover available (OTPLDB-OTPLDN).
20
282
OTD250 250W Modulo di input elettrico OTMIB OTMIN
Vin 220-240Vac Electrical input module 16
Vout 48 Vdc
Ampere 5.2 A 18
Articolo necessario per l’opzione
IP20
di alimentazione con driver remoti
92
(OTDS100-OTDS200-OTDRC).
280 16
Item required for power supply
option with remote drivers
42
(OTDS100-OTDS200-OTDRC). 2000
20
282
Driver remoto OTDS100 100W Schema regolazione cavi
Remote driver Vin 220-240Vac Cable adjustable scheme
Vout 48 Vdc
Ampere 2.1 A
Compatibile con qualsiasi sistema
IP20
48Vdc. Articolo necessario per
l’opzione di alimentazione con driver 36
A B
remoto, indispensabile il collegamento
al modulo di input elettrico (OTMIN- 22
OTMIB). Disponibile cover (OTCVB-
OTCVN).
Compatible with any 48Vdc system. 200 177 200
Item required for power supply option
with remote driver, indispensable
connection to electrical input module
(OTMIN-OTMIB). Cover available
OTDS200 Schema montaggio lente
(OTCVB-OTCVN). 200W
Vin 220-240Vac Lens assembly scheme
Vout 48 Vdc
Ampere 4.2 A
IP20

51
32
200 183 200
56 57
