Driver e alimentazione Driver and power supply

SQUARE incasso recessed SQUARE superficie surface ROUND superficie surface

nero bianco oro nero
Driver attacco magnetico black Cover per driver remoto white gold black
Magnetic attachment driver Cover for remote driver
OTD100 100W OTCVB OTCVG OTCVN
Vin 220-240Vac
Driver magnetico da installare Compatibile con driver
Vout 48 Vdc
direttamente a binario. Compatibile OTDS100 e OTDS200.
280 16 Ampere 2.1 A 65
con serie SQUARE 48Vdc - ROUND Compatible with OTDS100
IP20
48vdc. 42 and OTDS200 drivers. 45
Magnetic driver to be installed directly
on track. Compatible with SQUARE
20
48Vdc - ROUND 48vdc series.
282
300
BINARI MAGNETICI 48V 48V MAGNETIC TRACKS
Driver remoto per sospensione rigida
OTD150 150W OTDRC 100W
Vin 220-240Vac Remote driver for rigid suspension Vin 100-240Vac
Vout 48 Vdc Vout 48 Vdc
Ampere 3.1 A Articolo necessario per l’opzione di sospensione Ampere 2.1 A
IP20 rigida e alimentazione in remoto, indispensabile IP20
280 16 il collegamento al modulo di input elettrico SQUARE SUPERFICIE SQUARE SURFACE
97
(OTMIN-OTMIB). Disponibile asta con cover
(OTPLDB-OTPLDN).
42
Item needed for rigid suspension option and 30
remote power supply, indispensable connection to
20
282 electrical input module. (OTMIN-OTMIB). Rod with
129
cover available (OTPLDB-OTPLDN).
OTD250 250W Modulo di input elettrico OTMIB OTMIN
Vin 220-240Vac Electrical input module 16
Vout 48 Vdc
Ampere 5.2 A Articolo necessario per l’opzione 18
IP20
di alimentazione con driver remoti
92
280 16 (OTDS100-OTDS200-OTDRC).
Item required for power supply
option with remote drivers
42
(OTDS100-OTDS200-OTDRC). 2000
20
282
Driver remoto OTDS100 100W Schema regolazione cavi
Remote driver Vin 220-240Vac Cable adjustable scheme
Vout 48 Vdc
Compatibile con qualsiasi sistema Ampere 2.1 A
48Vdc. Articolo necessario per l’opzione IP20
di alimentazione con driver remoto, 36 A B
indispensabile il collegamento al
modulo di input elettrico (OTMIN- 22
OTMIB). Disponibile cover (OTCVB-
OTCVG-OTCVN).
Compatible with any 48Vdc system. 200 177 200
Item required for power supply option
with remote driver, indispensable
connection to electrical input module
(OTMIN-OTMIB). Cover available
OTDS200 Schema montaggio lente
(OTCVB-OTCVG-OTCVN). 200W
Vin 220-240Vac Lens assembly scheme
Vout 48 Vdc
Ampere 4.2 A
IP20

51
32

200 183 200

118 119
